Audio Research D-80 Tube Power Amp

Translation missing: en.products.product.price.regular_price $25,995.00
Translation missing: en.products.product.price.sale_price $25,995.00 Translation missing: en.products.product.price.regular_price
Translation missing: en.products.product.price.unit_price
Tax included.

The Audio Research D-80 is the kind of amplifier that makes audiophiles start talking about “air” with a straight face. Two KT150s per channel, fully balanced differential circuitry and a full-pentode design conspire to produce a soundstage with suspiciously good spatial hygiene, dense colours and bass that behaves like it has somewhere important to be. The D-80 borrows heavily from the Reference 80S, then throws just enough engineering restraint at the recipe to make it considerably less financially terrifying.

And then there’s the auto-bias, actively doing the obsessive-compulsive housekeeping while you sit there pretending you’re listening to the music rather than analysing the decay of a ride cymbal in the back-left corner. Balanced XLR inputs, 4/8/16 Ohm taps and a fully balanced output stage mean the D-80 is unapologetically serious about getting the signal from preamp to loudspeaker without wandering off to buy a scented candle. Built and individually auditioned in Minnesota, it has that rare Audio Research trick: making tubes, transformers and electrical engineering sound less like technology and more like someone has secretly removed a pane of glass from between you and the recording.

Shipping cost is based on weight. Just add products to our quote request form and we will get back to you with a shipping quote and a link to securely checkout online!
Ask a question

Ask a Question

* Required fields

Size guide Share
Audio Research D-80 Tube Power Amp

Audio Research D-80 Tube Power Amp

Product description
Shipping & Returns

Main Features & Specifications

  • All the info on the Audio Research D-80
  • Design: Fully Balanced Tube Power Amplifier
  • Power Output: 80 Watts continuous from 20Hz to 20kHz.
  • Total Harmonic Distortion: Typically 1% at 70 Watts, below 0.04% at 1 Watt
  • Power Bandwidth: (-3dB points) 7Hz to 68kHz
  • Frequency Response: (-3dB points at 1 watt) 0.7Hz to 94kHz
  • Input Sensitivity: 1.4V RMS for rated output (25.5 dB gain into 8 Ohms)
  • Input Impedance: 300K Ohms
  • Output Polarity: Non-inverting, Balanced input pin 2+ (IEC-268)
  • Output Taps: 4, 8, 16 Ohms
  • Output Regulation: Approximately 1.0dB 16 Ohm Load to Open Circuit (Damping factor approximately 8)
  • Overall Negative Feedback: 15dB
  • Slew Rate: 10 volts/microsecond
  • Rise Time: 4.0 microseconds
  • Tubes Required: 2 matched pair KT150 (Power output V1-V4); 2 6H30 (Gain stage V5, V6)
  • Available Finishes: Silver or Black (Special Order)
  • Width: 470 mm Chassis, 482.6 mm Faceplate
  • Height: 260 mm
  • Depth: 470 mm, 533 mm with Handles & Connectors
  • Weight: 28.2 kg
  • Manufacturer’s Warranty: 3 Years on Electronics, 90 Days on Tubes

Note: Features & Specifications Subject To Change Without Notice. E&OE.
